Molybdenum Sheet/Plate and Foil
Inquiry Now| Sr No | Product Code | Description | MOQ |
Sell Price (in AUD) |
|---|---|---|---|---|
| 1 | Mo-Plt-210-130-0.1th-0001 | 99.95% Molybdenum Plates 210 mm x 130 mm x 0.1 mm thickness | 2 | $30 |
| 2 | Mo-Plt-210-130-0.2th-0002 | 99.95% Molybdenum Plates 210 mm x 130 mm x 0.2 mm thickness | 2 | $60 |
| 3 | Mo-Plt-210-130-1.5th-0003 | 99.95% Molybdenum Plates 210 mm x 130 mm x 1.5 mm thickness | 1 | $250 |
| 4 | Mo-Plt-210-130-2.0th-0004 | 99.95% Molybdenum Plates 210 mm x 130 mm x 2.0 mm thickness | 1 | $300 |
| 5 | CUSTOM REQUIREMENT | We can customize your requirements as per your needs Email [email protected] or Call on +61478594746 | CONTACT US |
Product Description
Molybdenum plates, sheets, and foils are high-performance materials known for their exceptional strength, thermal stability, and resistance to extreme temperatures. These products are widely used in industries such as aerospace, electronics, and high-temperature furnaces due to their excellent conductivity, corrosion resistance, and mechanical stability. With a high melting point and outstanding durability, molybdenum plates, sheets, and foils provide reliable solutions for demanding applications.
Key Features
- High-Temperature Resistance – Can withstand extreme temperatures up to 2600°C.
- Excellent Thermal & Electrical Conductivity – Ideal for heat shields, furnace parts, and electronic components.
- Superior Strength & Hardness – Retains mechanical integrity under extreme conditions.
- Corrosion & Oxidation Resistance – Performs well in harsh environments, especially in vacuum or inert atmospheres.
- Customizable Sizes & Thicknesses – Available in various dimensions to meet specific application needs.
Technical Specifications
| Property | Specification | |
|---|---|---|
| Material | Pure Molybdenum (≥99.95% Purity) | |
| Density | 10.2 g/cm³ | |
| Melting Point | 2620°C | |
| Boiling Point | 4639°C | |
| Thermal Conductivity | 138 W/m·K at 20°C | |
| Electrical Conductivity | 1.87 × 10⁶ S/m | |
| Tensile Strength | 400 – 900 MPa (Varies by Thickness & Processing) | |
| Elongation | 10 – 30% | |
| Hardness (HV) | 200 – 250 HV | |
| Oxidation Resistance | Requires Protective Atmosphere Above 400°C | |
| Available Dimension | 0.05∼50.0mm (Thickness) x 50∼60mm (width) x 100∼3000mm (Length)(Customization requirements can be reviewed based on customer’s drawings/ request) | |
| Surface Finish | Hot Rolled, Cold Rolled, or Polished | |
| Processing Methods | Rolling, Cutting, Machining |
Applications
- Aerospace & Defense – Used in propulsion systems, heat shields, and structural components.
- Electronics & Semiconductor – Ideal for thin-film deposition, circuit boards, and high-precision components.
- High-Temperature Furnaces – Essential for heating elements, supports, and protective liners.
- Medical & Research Equipment – Applied in X-ray shielding, radiation protection, and laboratory instruments.
- Metal Processing & Coating – Used for sputtering targets, crucibles, and vacuum coating applications.
Why Choose Us?
- High-Purity & Precision Manufacturing – Guaranteed quality for optimal performance.
- Custom Sizes & Thicknesses – Tailored to meet specific application needs.
- Competitive Pricing – Cost-effective solutions without compromising on quality.
- Reliable Supply & Support – Ensuring timely delivery and expert technical assistance.
